Metric Coarse Full Nuts Grade 10 To DIN 934 Self Colour, Bright Zinc Plated, Hot Dipped Galvanised
| Diameter | Pitch | Depth of Nut | Across Flats |
| M3 | 0.5mm | 2.4mm | 5.5mm |
| M4 | 0.7mm | 3.2mm | 7mm |
| M5 | 0.8mm | 4mm | 8mm |
| M6 | 1.0mm | 5mm | 10mm |
| M8 | 1.25mm | 6.5mm | 13mm |
| M10 | 1.5mm | 8mm | 17mm |
| M12 | 1.75mm | 10mm | 19mm |
| M14 | 2mm | 11mm | 22mm |
| M16 | 2mm | 13mm | 24mm |
| M18 | 2.5mm | 15mm | 27mm |
| M20 | 2.5mm | 16mm | 30mm |
| M22 | 2.5mm | 18mm | 32mm |
| M24 | 3.0mm | 19mm | 36mm |
| M27 | 3.0mm | 22mm | 41mm |
| M30 | 3.5mm | 24mm | 46mm |
| M33 | 3.5mm | 26mm | 50mm |
| M36 | 4mm | 29mm | 55mm |
